Japan APOLLOWAVE Semi-automated Probe Station AP-150

Japan APOLLOWAVE Semi-automated Probe Station AP-150

AP-150 6-inch semi-automated probe station offers precise manual and automated wafer probing with motorized stage movement, programmable testing sequences, high-accuracy probe placement and compatibility with up to 6-inch wafers.
6-inch Semi Auto probe station AP-150.jpg
/
/
/
  • 6-inch Semi Auto probe station AP-150.jpg
  • AP150-4.jpg
  • AP150-2.jpg
DETAIL

Japan APOLLOWAVE Semi-automated Probe Systems AP-150

- Corresponding to various setting such as low leak measurement, High voltage/High current measurement,High frequency

- Compact design with 500m depth

- Control software with operational good performance

- Option line up  <probe aligments for verticality probe, auto alignment function>

＜Measurement example＞

fA level low leak measurement

High power measurement (more than 3kV, 100A)

High frequency measurement for millimeter wave

Enable to have high performance measurement which have comparable level as tester’s spec with using triaxial probe, HV triaxial probe and HC probe together

Accommodate millimeter wave with using Allstron’s RF probe

Calibration kit stage is also equipped as standard
